Amana Tool - 55341 Carbide Tipped Reversible Ogee Window Sash & Rail 1/8 Radius x 1-3/8 Di

Product Description This Reversible assembly is designed to cut window sash and glass door parts, including rails, stiles, mullions, and muntins, on stock between 1-1/8" And 1-3/4" Thick. Assembly includes an ogee profile Cutter, a rabbet Cutter, one bearing, a 1/2" Shank Arbor, spacers, shims, and washers. Configure as shown in the drawing to cut profile and rabbet on all parts. Switch bearing and profile Cutter and replace rabbet Cutter with spacers to rout the copes. Use in a table-mounted router, #55341, diameter (D): 1-3/8, radius (r): 1/8, cutting Height (B): 21/32, shank (D): 1/2, overall length (L): 2-1/8, B1: 1/16, B2: 27/64, 55341 carbide Tipped reversible Ogee window sash & rail 1/8 radius x 1-3/8 dia x 21/32 x 1/2 inch Shank with center ball bearing From the Manufacturer Since 1972, Amana Tool has been producing router bits and has become the global leader in its field. In fact, the company was the first manufacturer to produce router bits according to the Holz BG German standard for safety and quality. This standard contains rules that determine the structure and quality of the tool's material in order to create the safest environment for the user. From its beginning, Amana Tool has always used the highest quality materials, and its tools are produced using unique technologies, a majority of which were developed and built by the company's engineers following decades of testing and experience. For example, Amana Tool uses carbon alloy steel for its router bits that contains vanadium particles. This improves the structural integrity of the steel and prevents corrosion and defects in the internal structure of the material that can lead to cracks and breaks. High-tech machinery processes the carbon alloy steel to manufacture the router bodies in a single clamping. This yields router bits with superior balance, centricity, precision and symmetry.This reversible assembly is designed to cut window sash and glass door parts, including rails, stiles, mullions and muntins, on stock between 1-1/8-Inch and 1-3/4-Inch thick. Assembly includes an ogee profile cutter, a rabbet cutter, one bearing, a 1/2-Inch shank arbor, spacers, shims, and washers.

• Diameter (D): 1-3/8
• Radius (R): 1/8
• Cutting height (B): 21/32
• Shank (D): 1/2
• Overall length (L): 2-1/8
