2X DIN-Rail Serial Port RS485 to Ethernet Converter Server Protoss MQTT PE11-H Support Modbus RTU,2 x DIN-Rail Serial Server,White

-M3 MCU with 2MB Flash and 128KB <br>Use FreeRTOS Operation System<br>Support /UDP/MQTT/HTTP/WebSocket Protocol<br>Support Modbus to RTU, Modbus Master Function<br>Support RS485 To 10/100M Ethernet Conversion, Serial to 460800 bps<br><br>Support 10/100M Ethernet Auto-Negotiation<br>Support Webpage Easy Configuration or PC IOTService Tool<br>Support Security Protocol Such As /DES3<br>Support Heartbeat and Resister Packet Function<br>Support Webpage OTA Wireless Upgrade<br>Support Industrial Temperature:-40℃ to +85℃<br>Multiple Type of Different Power Input:<br>Protoss-PE11-H:100-240VAC@50-60Hz<br>Protoss-PE11-M:9-48VDC@1A<br>Work Temp:-40℃-85℃<br>Network Transformer:Integrated<br>Processor:-M3<br>Basic Frequency:96MHz<br>Flash:2MB<br>SDRAM:128KB<br>:FreeRTOS<br>Ethernet:1<br>Interface Standard:10/100M Base-T Auto-Negotiation<br>Network Protocol:IP, , UDP, DHCP, DNS, HTTP Server/Client, , AutoIP, ICMP, Telnet, NTP, Modbus <br>Security Protocol: 1.2 128Bit DES3<br>Port Number:EE10:1 RS232 EE11:1 RS485<br>Data Bits:5,6,7,8<br>Stop Bit:1,2<br>Check Bit:None,Even,Odd<br>Baud Rate:TTL:600 bps-460800bps<br>Flow Control:No Flow Control Half Flow Control(RS485) Software Xon/ Xoff flow control<br>Storage Temp:-45℃- 105℃,5 - 95% RH<br>Input Voltage:Protoss-PE11-H:100-240VAC@50-60Hz Protoss-PE11-M:9-48VDC@1A<br>Power:Less than 400mW<br>Colour:White<br>Material:Plastic<br>Size:97.60 x 64.95 x 27.50 mm (L x W x H),C45 rail installation<br><br>Package Contents:<br>2 x DIN-Rail Serial Server<br><br>Only the above package content, other products are not included.<br>Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
